Muscle
|
 Click on image for larger view |
|
|
Name
|
Quadriceps Femoris
|
|
|
Subdivision
|
vastus medialis
|
|
|
Muscle Anatomy
|
||
|
Origin
|
Distal half of the intertrochanteric line, medial lip of line aspera, proximal part of medial supracondylar line, tendons of adductor longus and adductor magnus and medial intermuscular septum. | |
|
Insertion
|
Proximal border of the patella and through patellar
ligament.
|
|
|
Function
|
Extension of the knee joint.
|
|
|
Recommended sensor placement procedure
|
||
|
Starting posture
|
Sitting on a table with the knees in slight flexion
and the upper body slightly bend backward.
|
|
|
Electrode size
|
Maximum size in the direction of the muscle fibres:
10 mm.
|
|
|
Electrode distance
|
20 mm.
|
|
|
Electrode placement
|
||
|
- location
|
Electrodes need to be placed at 80% on the line
between the anterior spina iliaca superior and the joint space in
front of the anterior border of the medial ligament.
|
|
|
- orientation
|
Almost perpendicular to the line between the anterior
spina iliaca superior and the joint space in front of the anterior
border of the medial ligament.
|
|
|
- fixation on the skin
|
(Double sided) tape / rings or elastic band.
|
|
|
- reference electrode
|
On / around the ankle or the proc. spin. of C7.
|
|
| Clinical test | Extend the knee without rotating the thigh while applying pressure against the leg above the ankle in the direction of flexion. | |
| Remarks |
The SENIAM guidelines include a separate sensor
placement procedure for the vastus lateralis and the rectus femoris
muscle.
|
|
